by U.S. Off Road on May 13, 2023 Categories: Technical Articles

User manuals and/or installation documents can be found below.

Winch Mount Installation Docs:

Toyota FJ Cruiser 2007-2014

Toyota FJ Cruiser 2007-2014 Addendum for JDM/AUS/Middle East markets

Toyota Tacoma 2005-2011

Toyota Tacoma 2012-2015

Toyota Tacoma 2016-2023

Toyota 4Runner 2014-2019

Other Products:

Toyota FJ Cruiser 2007-2014 Camera Armor

Technical Information:

Winch Selection - Which is the right winch for you?

Installation Videos - All FJ related but the process is identical to our other winch mounts.

Winch Fitment - Which winches work well with our winch mounts? The answer is that most do.

Paint and Coatings - What is best for your winch mount, how to do it and what are your options?

Winch Rope Installation & Care:

Whether it is a new winch (respool even if it's already spooled from the manufacturer) or you have used it while on the trail or just have it spooled out for cleaning, there are a few ways to tackle proper winch rope/cable spooling.

MasterPull winchline installation: http://www.masterpull.com/how-to-install-a-synthetic-winch-line/

Warn Rope Installation Guide (pdf): https://www.warn.com/Attachment/DownloadFile?downloadId=1455

Regarding cleaning, whether rope or steel cable, it should be spooled out (you can leave it attached to the drum), cleaned with soap and water then left to dry before respooling. I suggest a light coat of WD-40 or Gibbs Penetrant (much better) on steel cable. Do this every 6 months even if you haven't used it. You need to work the winch anyway every so often.

While you have the rope/cable spooled out, give your winch a good cleaning and a coat of wax. Don't laugh, most winches are powder coated and will last much longer if kept clean. Gibbs Penetrant is another great solution for coating fasteners and other metal components, just don't get it on the spool.



If you can't find your answers here or on our product pages then use the chat at bottom right or contact us here
